Croydon architectural drawings
Plans for extensions, lofts and building regs in Croydon
Local London designers • Fixed fee guaranteed • Council-ready drawings
WEDRAWPLANS prepare planning and technical drawings for Croydon homes, including extensions, loft conversions, refurbishments and outbuildings. Fixed fees with clear scope and fast communication. Close to East Croydon and West Croydon stations, with projects also covering Purley and Coulsdon streets.
- • Measured survey within 48 hours
- • Planning, Prior Approval or LDC route confirmed early
- • Rear, side and wrap around extensions
- • Loft dormers and hip to gable conversions
- • Building regulation packs for 2025 standards
- • Same day response on most enquiries
Recent projects in Croydon include rear extensions, side returns and loft conversions across CR0, CR2, CR5 and CR7.
Free fixed fee quote
Tell us a little about your property and what you plan to build. We will reply with a clear fixed fee for your drawings.
Popular services in Croydon
We provide full design and planning services for extensions, loft conversions and new build developments. Each service page explains what is included, how approvals work, and how to get a fixed quote.
Nearby borough pages
Explore our local pages for nearby boroughs. If you are close to the border, these pages may be relevant for your project.
Architectural drawing services in Croydon
WEDRAWPLANS prepare full drawing packages for rear and side extensions, loft conversions, refurbishments, internal alterations, outbuildings and small residential development projects across Croydon.
We cover Croydon, South Croydon, Purley, Coulsdon, Kenley, Sanderstead, Selhurst, Thornton Heath, Norbury, Shirley, New Addington and nearby streets.
Technical drawings builders can price from
Clear floor plans, elevations, sections and notes, coordinated with structural design so builders and inspectors have what they need.
Croydon areas we cover
Drawings for the whole borough of Croydon, including:
- Croydon
- South Croydon
- Purley
- Coulsdon
- Kenley
- Sanderstead
- Thornton Heath
- Norbury
- Shirley
- New Addington
- Selhurst
- Surrounding streets and estates
Popular projects in Croydon
- 3 m and larger rear extensions
- Wrap around and L shaped extensions
- Side extensions and infill extensions
- Hip to gable loft conversions
- Rear dormers with ensuite
- Garage conversions
- Internal reconfiguration
- Outbuildings and studios
- Flats, HMOs and change of use
- Small new build schemes
Permitted development limits in Croydon
This is a simplified guide to common permitted development limits. Final confirmation depends on your house type, location and any Article 4 directions.
Rear extensions
- Up to 3 m deep on terrace houses
- Up to 4 m on semi detached houses
- Up to 6 to 8 m with Prior Approval
- Maximum 4 m high for single storey
Loft conversions
- Up to 40 to 50 cubic metres volume
- No extensions on the front roof slope
- Side windows obscure glazed and fixed
- External materials to be similar
Outbuildings
- Maximum 2.5 m high near boundaries
- Cannot be used as a separate dwelling
- Use must be incidental to the house
- Not more than 50 percent of garden area
Planning drawings for Croydon
- Existing and proposed floor plans
- Existing and proposed elevations
- Roof plans and key sections
- Block plans and location plans
- Drainage and construction notes
- Design statements where required
Building regulation drawings for Croydon
- Structural layouts and coordination with engineer
- Foundation, beam and bearing information
- Fire safety and escape routes
- Thermal build ups and insulation specs
- Ventilation and extract positions
- Drainage runs and manhole information
Frequently asked questions in Croydon
Do I need planning permission for a rear extension in Croydon
Not always. Many rear extensions can be permitted development, but it depends on your house type, site constraints, and whether any restrictions apply. We confirm the best route after a quick review of your address and goals.
How long does Croydon Council take to decide
Timescales vary, but householder applications are commonly decided within several weeks after validation. If you need certainty for a permitted development style scheme, a Lawful Development Certificate can be a safer option.
Do you manage the full application to Croydon Council
Yes. We prepare drawings, complete forms, upload documents, submit to the council portal, and respond to planning officer queries through to decision.
What drawings do I get for building regulations
A coordinated package typically includes plans, elevations, sections, key construction details, notes for compliance, and coordination points for structure, ventilation, insulation, and drainage so builders can price and build correctly.
Local planning knowledge for Croydon projects
Croydon includes conservation areas, mixed housing stock and many family homes with scope for larger extensions and loft conversions. We shape each scheme to suit local character and neighbour amenity so approval chances are as strong as possible.
Ready to start your project
Send your postcode and a short description. We review and reply with a fixed fee and recommended next steps.
