Kingston upon Thames architectural drawings
Plans for extensions, lofts and new builds in Kingston
WEDRAWPLANS prepare planning and technical drawings for house extensions, loft conversions, refurbishments and conversions across the Royal Borough of Kingston upon Thames. Fixed fees with clear scope and fast communication.
- • Rear extensions, side extensions and wrap around layouts
- • Loft conversions including dormers and hip to gable
- • Refurbishments, internal re planning and structural openings
- • Planning drawings and building regulation packs
- • Covering Surbiton, New Malden, Chessington and more
- • Same day response on most enquiries
Free fixed fee quote
Tell us a little about your property and what you plan to build. We will reply with a clear fixed fee for your drawings.
Popular services in Kingston upon Thames
We provide full design and planning services for extensions, loft conversions and new build developments. Each service page explains what is included, how approvals work, and how to get a fixed quote.
Nearby borough pages
Explore our local pages for nearby boroughs. If you are close to the border, these pages may be relevant for your project.
Architectural drawing services in Kingston upon Thames
WEDRAWPLANS provide full drawing packages for single and double storey extensions, loft conversions, internal alterations, outbuildings and refurbishment projects across Kingston upon Thames.
We work throughout Surbiton, New Malden, Chessington, Norbiton, Tolworth, Berrylands, Kingston Vale and nearby riverside areas.
Technical drawings builders can price from
Clear floor plans, elevations, sections and notes, coordinated with structural design so builders and inspectors have what they need.
Kingston areas we cover
Drawings for the whole borough of Kingston upon Thames, including:
- Kingston upon Thames
- Surbiton
- Berrylands
- Norbiton
- New Malden
- Old Malden
- Tolworth
- Chessington
- Kingston Vale
- North Kingston
- Thames riverside area
- Nearby estates and streets
Popular projects in Kingston
- Large rear kitchen extensions
- Wrap around and L shaped extensions
- Side extensions and garage conversions
- Loft conversions and dormers
- Hip to gable loft conversions
- Garden studios and outbuildings
- Internal re planning for family living
- Refurbishment and compliance upgrades
- Roof changes in sensitive streets
- Energy and insulation upgrades
Permitted development limits in Kingston
This is a simplified guide to common permitted development limits. Final confirmation depends on your house type, location and any conservation constraints.
Rear extensions
- Up to 3 m deep on terrace houses
- Up to 4 m on semi detached houses
- Up to 6 to 8 m with Prior Approval
- Maximum 4 m high for single storey
Loft conversions
- Up to 40 to 50 cubic metres volume
- No extensions on the front roof slope
- Side windows obscure glazed and fixed
- External materials to be similar
Outbuildings
- Maximum 2.5 m high near boundaries
- Cannot be used as a separate dwelling
- Use must be incidental to the house
- Not more than 50 percent of garden area
Planning drawings for Kingston
- Existing and proposed floor plans
- Existing and proposed elevations
- Roof plans and key sections
- Block plans and location plans
- Drainage and construction notes
- Design and heritage statements where needed
Building regulation drawings for Kingston
- Structural layouts and coordination
- Foundation and beam information
- Fire safety and escape routes
- Thermal build ups and insulation specs
- Ventilation and extract positions
- Drainage runs and manhole information
Local planning knowledge for Kingston projects
Kingston includes riverside settings, conservation areas and character roads where massing, roof form and neighbour impact are assessed carefully. We shape each scheme to fit local context so approval chances are as strong as possible.
Frequently asked questions
Do I need planning permission in Kingston
Many houses can proceed under permitted development, but flats and conservation areas often need planning permission. We check your address and advise the best route at the start.
How fast can you survey
In most cases we can arrange the initial measured survey within forty eight hours of instruction.
Do you submit to Kingston Council
Yes. We handle the submission, monitor progress and respond to planning officer queries.
Can you coordinate structural design
Yes. We coordinate with structural engineers so beams and load paths are designed and shown correctly on the drawings.
Ready to start your project
Send your postcode and a short description. We review and reply with a fixed fee and recommended next steps.
